LPC-150-1050 – Mean Well LED Driver LPC-150-1050 Series 1050mA 151.2W Discount

Constant current designProtections: Short circuit Over voltage Over temperatureHigh efficiency up to 90%Cooling by free air convectionFully encapsulated with IP67 levelFully isolated plastic caseClass II power unit, no FGSuitable for LED lighting and moving sign application100% full load burn-in testLow Cost, High reliability2 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
151.2

Output Current
1050mA

Dimmable (Type)
No

Output Voltage Range (V)
72~144

DC Output Adjustment
72-144V

Dimensions
191x 63x 37.5

EMC Standards
Compliance to EN55022(CISPR22) Class B; EN61000-3-2 Class A (<80% load); EN61000-3-3, Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A

Input Voltage
180-305VAC

Safety Standards
IP67 approved, refer to EN60950-1

Output Voltage Options
Single

Working Temperature
-25°C-+50°C

PDF Datasheet
LPC-150-spec.pdf
