HLG-80H-15A – Mean Well LED Driver HLG-80H-15A 80W 15V Sale

IP65 design for indoor or outdoor installationsBuilt-in active PFC, PF>0.9 for 60% of load or higher5 years warrantyProtections: Short circuit Over current Over voltage Over temperatureOther features:Universal AC input (up to 305VAC) Full rangeHigh efficiency up to 94%Output current adjustable through output cable or internal potentiometerCooling by free air convectionSuitable for dry, damp and wet locationSuitable for LED lighting and street lighting applicationsMeet 4KV surge immunity level (IEC61000-4-5)Class 2 power unitOutput voltage and C.C level can be adjusted through internal potentiometer
More Information

Manufacturer
Mean Well

Output Wattage (W)
80

Output Voltage
15V

Dimmable (Type)
1-10VDC, PWM signal, resistance

DC Output Adjustment
+ -10% rated output voltage

EMC Standards
EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024

Input Voltage
90~305VAC, 127~431VDC

Safety Standards
UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-2-13 approved; Design refer to UL60950-1, EN60950-1

Output Voltage Options
Single

Working Temperature
-40~+50°C (refer to output derating curve)

PDF Datasheet
HLG-80H-spec_16.pdf
