HLG-60H-C700A – Mean Well LED Driver HLG-60H-C700A 70W 700mA Discount

Constant current designOutput current adjustable through internal potentiometerProtections: Short circuit Over voltage Over temperatureUniversal AC input Full range (up to 305VAC)Built-in active PFC functionCooling by free air convectionIP65 design for indoor or outdoor installationsSuitable for dry damp wet locationsHigh efficiency up to 91%5 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
70

Output Current
700mA

Dimmable (Type)
1-10VDC, PWM signal, resistance

Dimensions
171x 61.5x 36.8

EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (¡Ù60% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, heavy industry level (surge L,N-FG: 4KV), criteria A

Input Voltage
90~305VAC, 127VDC~431VDC

Safety Standards
UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13 independent, IP65 approved

Output Voltage Options
Single

Working Temperature
-40~+50°C (refer to output derating curve)

PDF Datasheet
HLG-60H-C-spec.pdf
