HLG-150H-12B – Mean Well LED Driver HLG-150H-12B 150W 12V Sale
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
IP67 design for indoor or outdoor installationsBuilt-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)5 years warrantyProtections: Short circuit Over current Over voltage Over temperatureOther features:Universal AC input (up to 305VAC) Full rangeHigh efficiency up to 95%Output current adjustable through output cable or internal potentiometerCooling by free air convectionSuitable for LED lighting and street lighting applicationsMeet 4KV surge immunity level (IEC61000-4-5)Optional CQC models availableBuilt-in active PFC, PF>0.9 for 60% of load or higher
More Information
Manufacturer
Mean Well
Output Wattage (W)
150
Output Voltage
12V
DC Output Adjustment
+ -10% rated output voltage
EMC Standards
EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547
Input Voltage
90~305VAC, 127~431VDC
Safety Standards
UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13, UL1012, UL60950-1
Output Voltage Options
Single
Working Temperature
-40~+70°C
PDF Datasheet
HLG-150H-spec.pdf
