HLG-120H-C1400A – Mean Well LED Driver HLG-120H-C1400A 151W 1400mA For Discount

$37.86

20 people are viewing this right now
2 products sold in last 4 hours
Selling fast! Over 16 people have this in their carts
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

Constant current designUniversal AC input Full range (up to 305VAC)Protections: Short circuit Over voltage Over temperatureBuilt-in active PFC functionHigh efficiency up to 94%Cooling by free air convectionOutput current adjustable through internal potentiometerIP65 design for indoor or outdoor installationsSuitable for dry damp wet locations5 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
151

Output Current
1400mA

Dimmable (Type)
1-10VDC, PWM signal, resistance

Output Voltage Range (V)
54 ~ 108

Dimensions
220x 68x 38.8

EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (?50% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, heavy industry level (surge L,N-FG: 4KV), criteria A

Input Voltage
90 ~ 305VAC, 127~431VDC

Safety Standards
UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13, EN62384 independent, IP65 approved

Output Voltage Options
Single

Working Temperature
-40~+70°C

PDF Datasheet
HLG-120H-C-spec.pdf
