CEN-60-12 – Mean Well LED Driver CEN-60-12 60W 12V Cheap

$33.36

23 people are viewing this right now
15 products sold in last 8 hours
Selling fast! Over 10 people have this in their carts
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

Built-in active PFC function, PF>0.9 for 75% of load or higherIP66 designProtections: Short circuit Over current Over voltage Over temperatureOther features:Universal AC input (up to 295VAC) Full rangeMeet 4kV surge immunity level (IEC61000-4-5)Class 2 power unitCooling by free air convectionSuitable for dry,damp and wet locationSuitable for LED lighting and moving sign applications3 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
60

Output Voltage
12V

Dimmable (Type)
No

DC Output Adjustment
+ -10% rated output voltage

Dimensions
183 x 62.5 x 40.5

EMC Standards
EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547

Input Voltage
90~295VAC, 127~417VDC

Safety Standards
UL8750, UL879, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13

Output Voltage Options
Single

Working Temperature
-30~+70°C (refer to output derating curve)

PDF Datasheet
CEN-60-SPEC.PDF
