CEN-100-48 – Mean Well LED Driver CEN-100-48 100W 48V Cheap

$38.11

29 people are viewing this right now
6 products sold in last 12 hours
Selling fast! Over 11 people have this in their carts
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

Built-in active PFC function, PF>0.9 for 75% of load or higherIP66 designProtections: Short circuit Over current Over voltage Over temperatureOther features:Universal AC input (up to 295VAC) Full rangeMeet 4kV surge immunity level (IEC61000-4-5)Class 2 power unitCooling by free air convectionSuitable for dry,damp and wet locationSuitable for LED lighting and moving sign applications3 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
100

Output Voltage
48V

Dimmable (Type)
No

DC Output Adjustment
+ -10% rated output voltage

Dimensions
193 x 62.5 x 40.5

EMC Standards
EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN6154724pcs

Input Voltage
90~295VAC, 127~417VDC

Safety Standards
UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13

Output Voltage Options
Single

Working Temperature
-30~+70°C (refer to output derating curve)

PDF Datasheet
CEN-100-SPEC.PDF
